ADC Pi
ADC Pi Tutorials
Created 27/07/2024 | Last Updated: 30/07/2024
The ADC Pi is an 8-channel 17-bit analogue to digital converter designed to work with the Raspberry Pi and other compatible single-board computers. The ADC Pi is based on two Microchip MCP3424 A/D converters, each containing 4 analogue inputs. The MCP3424 is a delta-sigma A/D converter with low noise differential inputs.
This knowledge base section contains articles and tutorials on the ADC Pi, showing how to use the development board with a range of input devices.
